ZONE 1/21

Tablet

RxIST401

IS Tablet

RxAltitude

IS Tablet

With Realix's focus on innovation in the field of connected plant we are glad to introduce RxAltitude, an IS Tablet especially built to be used in hazardous areas. With special focus given to ease of use while making it fully functional under most challenging environment providing maximum safety in the field.

This ATEX certified mobility device comes pre-loaded with some of the best in class communication media and integrated softwares to help clients manage and transform their plants digitally to Industry 4.0 standards.

Being one of lightest device in the market it still houses a big battery which supports a longer on-field connectivity.

RxAltitude
RxAltitude

Ideal for IIOT

Our commitment towards Open standard solutions is well modeled into this unit. Utilizing various sensors that are out-of-the-box with this tablet helps you build a customized solution that would move you towards achieving your automation and connected plant goals.

To run various resource-demanding software solutions this device comes with a power-packed Octa-Core processor and to complement that an 8500mAh battery.

Features

INTRINSICALLY SAFE

Explosion Proof / ATEX Zone 1/21

LIGHT WEIGHT

One of the lightest with 715gms

OPERATING TEMPERATURE

RANGES -20°C to 60°C

OPERATING SYSTEM

Android 9.0

ULTRA-RUGGED

Dust and Water-resistant (IP67)

MEMORY 64GB ROM & 4GB RAM

Micro-SD - Expandable up to 128GB

Technical Data

  • MAIN CHARACTERISTICS
  • CONNECTIVITY
  • PHYSICAL CHARACTERISTICS
Operating System Android 9.0
Processor MSM8953 (2.0GHz) Octa core
Display 8" Rug Multi-point Display, 800x1280 IPS LCD
Multi-point Capacitive, Anti-scratch, Support handwriting
GPU Adreno 506 1920 × 1200 @ 60 fps
Memory 64GB ROM & 4GB RAM
MicroSD - Expandable up to 128GB
Blue-tooth 4.1 (BLE)
GPS GPS (frequency:1575.42MHz) + Glonass (frequency:1602MHZ)
Sensors L-Sensor, Compass, Gyro Sensor, G_sensor
NFC Enabled. Card reading distance: 3cm~5cm
Network Single SIM 4G LTE
WIFI WIFI 802.11 (2.4GHz + 5GHz dual band WIFI)
USBStandard USB 2.0
Earphone JackStandard 3.5mm
HDMIHDMI 1.4a Type C
Extensive Slot12pin Pogo Pin
Operating Temperature -20 °C to +60 °C
Protection Class  IP67
Camera(s) 13MP rear auto-focus with flashlight, 5MP front.
Battery 8500mAh Lithium-ion battery
Dimensions 228 x 145 x 16.5 mm
Weight 715gms

Our CERTIFICATION

ATEX
II 2G Ex ib IIC T4 Gb IP68
II 2D Ex ib IIIC T135°C Db IP68
Ta: -20°C +60°C
